Pin Mill

Widely used in chemical, inorganic salt, medicine, food, pigments, dyes, pesticides, battery materials, minerals, refractory materials and other industries.
The pin mill also categorized as a disc mill is a kind of milling equipment that can break up cellular materials selectively without damaging the starch granules. It consists of two horizontal steel plates with vertical projections arranged in concentric circles on opposing faces and becomes more closely spaced towards the periphery.

Get A Quote

    Please prove you are human by selecting the house

    Contact Us

    Working Principle Of Pin Mill

    Pin mill work by similar principle as hammer mills (impacts and shearing) but with typically faster tip speed rotor-stator configuration of intermeshing pins which impact the particles as solids are directed through the intermesh pins. The mill product leaves by centrifugal forces to the periphery and is then collected or further processed. This method of milling is most likely to produce materials in the micronized regime (as less than 40 micrometres) and with uniform product size. Cooling of the rotating disks is a useful way of removing heat from the mill.

    The materials are uniformly fed into the grinding chamber by the feeding system, and are strongly impacted by the high-speed rotating grinding movable disk. At the same time, they are subjected to various comprehensive forces such as friction, shearing, and collision between the static disk and the gear ring, so that the materials are crushed. According to the different properties of the materials, the grinding movable disk and the static disk can be combined with different structures to meet the crushing needs of different materials.

    Advantages of Pin Mill

    It achieves smaller particle size than hammer mill at relatively reasonable energy consumption.
    Recent advances have improved heat removal from the mill using cryogenic conditions.
    Pin mill occupies little floor space.
    It has a wide range of applications; can be used in milling dry, moist or slurry materials.
    The two needle discs in the mill rotate at high speed in opposite directions;
    The fineness of the product is achieved by adjusting the speed of the dial;
    The machine is easy to clean, just open the grinding door;
    No sieve, smooth discharge, high capacity and low operation cost; dual power can be used to achieve a linear speed above 200m/s to obtain greater crushing power.

    Technical parameters of horizontal Pin Mill

    Type Model 200 400 500 630 800
    coarse powder Fineness (mesh) 20 - 200 20 - 200 20 - 200 20 - 200 20 - 200
    Speed (m/s) 75 - 85 75 - 85 75 - 85 75 - 85 75 - 85
    Power(kw) 7.5 18.5 22 37 55
    Fine powder Fineness (mesh) 60 - 300 60 - 300 60 - 300 60 - 300 60 - 300
    Speed (m/s) 100 - 120 100 - 120 100 - 120 100 - 120 100 - 120
    Power (kW) 11 30 37 55 75
    Superfine powder Fineness (mesh) 100 - 2500 100 - 2500 100 - 2500 100 - 2500 100 - 2500
    Speed (m/s) 200 - 240 200 - 240 - 200 - 240 200 - 240
    Power (kw) 11*2 30*2 - 55*2 90*2

    Show Details Of Our Pin Mills

    Details Of Our Pin Mill
    Details Of Our Pin Mill
